• Illumination of loading and offloading applications mounted on loading machine
• Illumination of objects over long distances
• Stainless steel housing
• 1 x 72 W High Power LED, focused lightbeam with lenses
• Various frames and holders available, based on customer needs
• Radiation resistant

Illumination
Distance/Luminance/Diameter of light beam in air
5m/9200 LUX/0,42 m
12m/1300 LUX/1,1 m
15m/1020 LUX/1,3 m

• Dimensions/Weight Length: 430 mm, Diameter 65-68 mm, Weight 2,7kg
• LED Type: 1 x 72 Watt High Power LED (approx. 100000h lifetime)
• Power supply: 110V/220V
• Housing: Stainless steel
• Operating temperature: 0 – 50°
• Depth rating: up to 5 bar
• Radiation tolerance: >5×10⁴ Gy / 5×10⁶ rad (cumulative dose/total dose)
